RYOBI 2 HP 10-Amp Plunge Base Router w/bits

Corded electric tool is designed for precision woodworking tasks like routing grooves, shaping edges, and making plunge cuts up to 2 inches deep

Key Features and Specifications

Motor: 10-Amp motor delivering 2 peak horsepower.

Variable Speed: Electronic speed control ranging from 15,000 to 25,000 RPM. The dial uses a six-step scale (A to F), where 'F' is the fastest.

Collet Size: Features a 1/2-inch collet and includes a 1/4-inch adapter to accommodate a wide variety of router bits.

Depth Adjustment: Includes an ACCU-STOP micro-adjustable depth stop for precise, repetitive cuts.

Soft Start: Gradually increases speed upon startup to prevent surface damage and reduce kickback.

Spindle Lock: Allows for easy bit changes using a single wrench.

Basic Operation

Power: Use the toggle switch to turn the unit ON (I) or OFF (O).

Depth Setting: To set the depth, unlock the plunge lock lever, lower the router until the bit touches the surface ("zeroing"), and then adjust the stop bar to your desired depth before locking the lever back in place.

Changing Bits: Depress the spindle lock button and use the provided wrench to loosen the collet nut counterclockwise. Always unplug the tool before making any adjustments or changing bits.
